MSI B550M-A PRO DDR4 AMD AM4 Micro ATX Motherboard

-10 %

MSI B550M-A PRO DDR4 AMD AM4 Micro ATX Motherboard

Offer Price: 10,600৳
Price: 11,800৳
Stock: In Stock
Brand: MSI
Model: B550M-A PRO
Product Code: 812303

Based on 0 reviews. - Write a review

10,600৳

11,800৳

Ex Tax: 10,600৳

Qty

Add to Cart

Buy Now

Add to Wish List Compare this Product

Key Features

Supports AMD Ryzen 5000 & 3000 Series desktop processors
Supports DDR4 4600(OC)MHz
PCIe 4.0, Lightning Gen4 x4 M.2
2oz Thickened Copper PCB

View more details

Specification

Basic Information
Supported CPU	Supports AMD Ryzen 5000 & 3000 Series desktop processors (not compatible with AMD Ryzen 5 3400G & Ryzen 3 3200G) and AMD Ryzen 4000 G-Series desktop processors
Chipset	AMD B550
Audio	Realtek ALC892/ALC897 Codec
Expansion Slots
M.2 Socket	1x M.2
PCI	PCI-E X16 x 1 PCI-E (Gen4 / Gen3)
Memory Specifications
Maximum Memory	64GB
Slots	1x PCIe 3.0 x1 slot 1 1x PCIe 4.0/3.0 x16 slot The supported specification depends on the installed processor.
Supported Memory	2x DDR4 memory slots, support up to 64GB 1 Supports DDR4 1866/ 2133/ 2400/ 2667/ 2800/ 2933/ 3000/ 3066/ 3200 MHz by JEDEC Supports DDR4 2667/ 2800 /2933 /3000 /3066 /3200 /3466 /3600/ 3733 /3866 /4000 /4133 /4266 /4400/ 4600+ MHz by A-XMP OC MODE 1DPC 1R max speed 4600 MHz 1DPC 2R max speed 3866 MHz Dual-channel memory architecture Supports non-ECC UDIMM memory Supports ECC UDIMM memory (non-ECC mode) Supports un-buffered memory
Type	DDR4
Graphics Specifications
Graphics	1x HDMI 2.1 port, supports a maximum resolution of 4096x2160 @60Hz 1x DVI-D port, supports a maximum resolution of 1920x1200@60Hz Available for the processor with integrated graphics. Graphics specifications may vary depending on the CPU installed.
Max Shared Memory	16 GB
Connector & Ports
Audio	7.1-Channel High Definition Audio
HDMI	1 x HDMI
Internal I/O Ports	1x 24-pin ATX main power connector 1x 4-pin ATX 12V power connector 4x SATA 6Gb/s connectors 1x M.2 slots (M-Key) 1x USB 3.2 Gen 1 5Gbps connector (supports additional 2 USB 3.2 Gen 1 5Gbps ports) 2x USB 2.0 connectors (supports additional 4 USB 2.0 ports) 1x 4-pin CPU fan connector 1x 4-pin system fan connectors 1x Front panel audio connector 2x System panel connectors 1x Chassis Intrusion connector 1x Clear CMOS jumper
LAN Port (s)	1x Realtek RTL8111H Gigabit LAN
RAID	Supports RAID 0, RAID 1 and RAID 10 for SATA storage devices Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
Supported Storage	AMD B550 Chipset 4x SATA 6Gb/s ports 1x M.2 slot (Key M) (from AMD Processor) Supports PCIe 4.0/ 3.0 Supports SATA 6Gb/s Supports 2242/ 2260/ 2280 storage devices The supported specification depends on the installed processor.
TPM (Trusted Platform Module )	1 x TPM module connector
USB (s)	AMD B550 Chipset 2x USB 3.2 Gen 1 5Gbps ports are available through the internal USB 3.2 Gen 1 5Gbps connector 6x USB 2.0 ports (2 Type-A ports on the back panel, 4 ports through the internal USB 2.0 connectors) AMD Processor 4x USB 3.2 Gen 1 5Gbps Type-A ports on the back panel
Warranty Information
Warranty	3 years

Description

MSI B550M-A PRO AMD AM4 Motherboard – High Performance for Gamers & Professionals

The MSI B550M-A PRO AMD Motherboard is engineered for gamers, content creators, and professionals who demand stable performance, fast connectivity, and future-ready features. Supporting AMD Ryzen 5000 and 3000 series processors, this motherboard ensures outstanding efficiency for multitasking, high-end gaming, and productivity workloads in Bangladesh.

Key Features:

Supports AMD Ryzen Processors: Compatible with AMD Ryzen 5000 Series and 3000 Series Desktop CPUs for exceptional power and flexibility.
High-Speed DDR4 Memory: Supports DDR4 memory up to 4600(OC) MHz, ensuring faster loading times, improved multitasking, and stable system performance.
PCIe 4.0 Technology: Enables ultra-fast data transfer and superior graphics performance for the latest GPUs and storage devices.
Lightning Gen4 x4 M.2 Slot: Delivers lightning-fast storage speeds, reducing boot times and improving file transfer performance.
2oz Thickened Copper PCB: Enhances thermal performance and stability, ensuring durability under heavy workloads.

Why Choose MSI B550M-A PRO?

This motherboard is ideal for users who want high reliability, speed, and future-proof technology. Whether building a gaming rig, a professional workstation, or a multitasking PC, the MSI B550M-A PRO delivers robust performance and long-lasting durability.

MSI B550M-A PRO Unboxing and Overview

FAQ

Q1: Which processors are compatible with MSI B550M-A PRO?
A: It supports AMD Ryzen 5000 Series and 3000 Series Desktop Processors, ensuring high performance for gaming and productivity tasks.

Q2: What type of memory does this motherboard support?
A: The motherboard supports DDR4 memory up to 4600(OC) MHz, ideal for fast multitasking and stable performance.

Q3: Does it support PCIe 4.0?
A: Yes, it is equipped with PCIe 4.0, providing ultra-fast data transfer for the latest GPUs and NVMe storage solutions.

Q4: What is the advantage of the Lightning Gen4 x4 M.2 slot?
A: The Lightning Gen4 x4 M.2 slot ensures lightning-fast storage speeds, improving boot times and file transfers, especially for large files.

Q5: How does the 2oz thickened copper PCB help?
A: The 2oz thickened copper PCB enhances thermal performance, system stability, and durability, making it suitable for heavy workloads and long-term use.

Q6: Is this motherboard suitable for gaming and professional use?
A: Absolutely. With high-speed DDR4 support, PCIe 4.0, and future-ready features, it is perfect for gaming rigs, content creation, and multitasking PCs.
