GIGABYTE B650 AORUS ELITE AX DDR5 AMD AM5 Micro-ATX Motherboard
Original price was: 37,000.00৳ .33,500.00৳ Current price is: 33,500.00৳ .
Key Features
- Supported CPU: Ryzen 7000 Series Processors for Socket AM5
- Supported RAM: 4x DDR5, up to 128GB, 6666(OC)
- Graphics Output: 1x Display Port, 1 x HDMI
- Features: Realtek 2.5GbE LAN & AMD Wi-Fi 6E
Description
GIGABYTE B650 AORUS ELITE AX DDR5 AMD AM5 Micro-ATX Motherboard
The GIGABYTE B650 AORUS ELITE AX DDR5 AMD AM5 Micro-ATX Motherboard is engineered for next-gen gaming and professional performance. Built on the robust AMD B650 chipset, it supports AMD Ryzen 7000 and 8000 series processors, and brings together cutting-edge features like DDR5 memory compatibility, PCIe 5.0 M.2 support, and Wi-Fi 6E connectivity. Whether you’re building a powerful gaming PC or a high-performance workstation, this motherboard delivers top-tier reliability and future-ready specifications to push your system’s limits in every possible way.
Key Features of GIGABYTE B650 AORUS ELITE AX DDR5 AMD AM5 Micro-ATX Motherboard
Advanced DDR5 Memory Support
This motherboard supports blazing-fast DDR5 memory up to 6666MHz (OC), offering higher bandwidth, improved efficiency, and overclocking capabilities to supercharge multitasking and gaming performance.
Future-Proof CPU Compatibility
Designed for the AMD AM5 socket, it supports Ryzen 7000 and 8000 series CPUs, ensuring compatibility with the latest and upcoming AMD processors for years to come.
Ultra-Fast Storage with PCIe 5.0
Equipped with triple M.2 slots including PCIe 5.0 support, this board delivers lightning-fast NVMe SSD performance ideal for high-speed data access, content creation, and game loading.
Integrated Wi-Fi 6E & Bluetooth 5.3
Stay connected with AMD or Intel Wi-Fi 6E modules and Bluetooth 5.2/5.3 support, providing ultra-low latency, faster speeds, and a smoother online gaming and streaming experience.
2.5GbE High-Speed LAN
Experience stable and fast wired connections through the Realtek 2.5GbE LAN, ensuring low-lag online gameplay and improved file transfer performance.
Next-Level USB Connectivity
Enjoy an abundance of USB ports, including USB 3.2 Gen 2×2 Type-C and multiple Gen 1 and Gen 2 ports, allowing high-speed data transfers and easy connection for all your peripherals.
Enhanced Audio System
With Realtek High Definition Audio and support for 7.1-channel output, your games and media sound rich, detailed, and immersive through any speaker setup.
Robust Cooling and RGB Options
Multiple fan headers, water cooling support, and addressable RGB headers make this board a dream for enthusiasts looking to build a custom-cooled and visually stunning PC.
Built-In RAID Support
Supports RAID 0, 1, and 10 for both NVMe and SATA SSDs, offering flexible and secure storage configurations tailored to your performance needs.
Comprehensive Software and BIOS Features
Includes Q-Flash Plus for easy BIOS updates, GIGABYTE Control Center for full system management, and Norton Internet Security for built-in protection from the start.
Buy GIGABYTE B650 AORUS ELITE AX DDR5 AMD AM5 Micro-ATX Motherboard from Canvas IT in BD
If you’re looking to future-proof your PC with top-tier features, the GIGABYTE B650 AORUS ELITE AX is a powerhouse worth every penny. At Canvas IT in BD, you get authentic products with a 3-year official warranty, unbeatable customer service, and competitive pricing. Choose Canvas IT today for a smooth and trusted tech shopping experience that delivers right to your door.
What is the price of the GIGABYTE B650 AORUS ELITE AX Motherboard in Bangladesh?
The latest price of the GIGABYTE B650 AORUS ELITE AX Motherboard in Bangladesh is 33,500৳. You can buy the GIGABYTE B650 AORUS ELITE AX Motherboard at the best price from our website or visit any of our showrooms.
| Basic Information | ||
| Supported CPU | AMD Socket AM5, support for: AMD Ryzen 8000 & 7000 Series Processors | |
| Chipset | AMD B650 | |
| BIOS | 1 x 256 Mbit flash Use of licensed AMI UEFI BIOS PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0 |
|
| Form Factor | ATX Form Factor; 30.5cm x 24.4cm | |
| Audio | Realtek Audio CODEC High Definition Audio 2/4/5.1/7.1-channel * You can change the functionality of an audio jack using the audio software. To configure 7.1-channel audio, access the audio software for audio settings. Support for S/PDIF Out |
|
| Expansion Slots | ||
| PCI | CPU: 1 x PCI Express x16 slot, supporting PCIe 4.0 and running at x16 (PCIEX16) * For optimum performance, if only one PCI Express graphics card is to be installed, be sure to install it in the PCIEX16 slot. Chipset: 2 x PCI Express x16 slots, supporting PCIe 3.0 and running at x1 (PCIEX1_1/2) |
|
| Memory | ||
| Type | DDR5 | |
| Slots | 4 DIMMs | |
| Supported Memory | 6666(OC) / 6600(OC) / 6400(OC) / 6200(OC) / 6000(OC) / 5600(OC) / 5200 / 4800 / 4400 MT/s memory modules Dual channel memory architecture Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules Support for AMD EXtended Profiles for Overclocking (AMD EXPO) and Extreme Memory Profile (XMP) memory modules |
|
| Maximum Memory | 128GB | |
| Graphics | ||
| Graphics | Integrated Graphics Processor: 1 x DisplayPort, supporting a maximum resolution of 3840x2160@144 Hz * Support for DisplayPort 1.4 version and HDR. 1 x HDMI port, supporting a maximum resolution of 4096x2160@60 Hz * Support for HDMI 2.1 version and HDCP 2.3. ** Support native HDMI 2.1 TMDS compatible ports. |
|
| Connector & Ports | ||
| HDMI | 1x HDMI | |
| Internal I/O Ports | 1 x 24-pin ATX main power connector 1 x 8-pin ATX 12V power connector 1 x 4-pin ATX 12V power connector 1 x CPU fan header 1 x water cooling CPU fan header 3 x system fan headers 1 x system fan/water cooling pump header 2 x addressable LED strip headers 2 x RGB LED strip headers 1 x CPU cooler LED strip/RGB LED strip header 3 x M.2 Socket 3 connectors 4 x SATA 6Gb/s connectors 1 x front panel header 1 x front panel audio header 1 x USB Type-C header, with USB 3.2 Gen 2x2 support 1 x USB 3.2 Gen 1 header 2 x USB 2.0/1.1 headers 1 x reset button 1 x reset jumper 1 x Clear CMOS jumper |
|
| Display Port (s) | 1 x DisplayPorts | |
| USB (s) | CPU: 1 x USB Type-C port on the back panel, with USB 3.2 Gen 2 support 2 x USB 3.2 Gen 2 Type-A ports (red) on the back panel CPU + USB 2.0 Hub: 4 x USB 2.0/1.1 ports on the back panel Chipset: 1 x USB Type-C port with USB 3.2 Gen 2x2 support, available through the internal USB header 3 x USB 3.2 Gen 1 ports (1 port on the back panel, 2 ports available through the internal USB header) 4 x USB 2.0/1.1 ports available through the internal USB headers Chipset+USB 3.2 Gen 1 Hub: 4 x USB 3.2 Gen 1 ports on the back panel |
|
| LAN Port (s) | Realtek 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps) | |
| Supported Storage | CPU: 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 5.0* x4/x2 SSD support) (M2A_CPU) * Actual support may vary by CPU. 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD support) (M2B_CPU) Chipset: 1 x M.2 connector (Socket 3, M key, type 25110/2280 PCIe 4.0 x4/x2 SSD support) (M2C_SB) 4 x SATA 6Gb/s connectors |
|
| Audio | 3 x Audio jacks | |
| Wireless Communication module | AMD Wi-Fi 6E RZ616 (MT7922A22M) (For PCB rev. 1.0) WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.2 Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate Intel® Wi-Fi 6E AX210 (For PCB rev. 1.1) WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands BLUETOOTH 5.3 Support for 11ax 160MHz wireless standard and up to 2.4 Gbps data rate |
|
| TPM (Trusted Platform Module) | 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only) | |
| RAID | RAID 0, RAID 1, and RAID 10 support for NVMe SSD storage devices RAID 0, RAID 1, and RAID 10 support for SATA storage devices |
|
| Others | ||
| Special Features | Support for GIGABYTE Control Center (GCC) * Available applications in GCC may vary by motherboard model. Supported functions of each application may also vary depending on motherboard specifications. Support for Q-Flash Support for Q-Flash Plus |
|
| Bundled Software | Norton Internet Security (OEM version) LAN bandwidth management software |
|
| Warranty Information | ||
| Manufacturing Warranty | 3 Years | |
